Description

140 x 65 mm H3 primed GL10 beam: a glue-laminated (glulam) radiata pine beam, H3 LOSP treated and factory coated in a pink primer. It is used for exposed beams above ground, such as pergola, carport and verandah beams.

Key facts

  • Size: 140 x 65 mm
  • Lengths: 3.6, 4.8, 5.4, 6.0 and 7.2 m
  • Grade: GL10 glue-laminated (glulam)
  • Timber: radiata pine
  • Treatment: H3 LOSP, for outdoor use above ground
  • Finish: pink primer, ready for top coats
  • Weight: about 5.5 kg per metre (about 20 kg for 3.6 m, 39 kg for 7.2 m)
  • Sold as: single lengths

What it is used for

Pergola and carport beams, verandah beams, lintels and exposed framing above ground. H3 treatment is for outdoor timber that is clear of the ground, so this beam is not for use in the ground or in contact with it. For a deeper beam in the same thickness, see the 180 x 65 H3 primed GL10 beam.

Working with it

Size the beam and its span from the manufacturer's span tables or with your engineer. Seal any cut ends, notches and holes with a suitable end sealer before top coating. The pink primer is an undercoat, so apply two or more coats of quality exterior paint and keep the paint maintained. Store beams flat on bearers, off the ground and under cover until they are fixed. Use hot dipped galvanised or stainless steel fixings outdoors.

Common questions

How far will a 140 x 65 GL10 beam span?

That depends on the load, the beam spacing and what it supports. Use the manufacturer's span tables or ask your engineer. We do not publish span figures online.

How heavy is it?

About 5.5 kg per metre. A 6.0 m beam is about 33 kg, so plan on two people to lift and place it.

Can it go in the ground?

No. H3 is for outdoor use above ground. Timber in the ground needs H4 treatment or higher.

Can I pick it up or get it delivered?

Yes. Pick up from our store at 10 Lancaster Street, Ingleburn, or have it delivered across Sydney. Lengths run to 7.2 m, so bring a vehicle that can carry them or call (02) 4605 0215 for a delivery quote.

Specifications
Brand
Alpha Timber
Product type
Primed Timber
Size options
3.6m, 4.8m, 5.4m, 6.0m, 7.2m
SKU
25065
Prices
Include GST
Ask a human expert

Not sure on size, length or quantity? Talk to our team — Mon–Fri 6am–4pm, Sat 6am–3pm.

Call 02 4605 0215

Delivery & Click + Collect

Pick up from 10 Lancaster Street, Ingleburn, or have it delivered to site across Greater Sydney. Ask us for a delivery price to your site.

Delivery & collection details

140 x 65 H3 primed GL10 glulam beam, treated pine, 3.6 to 7.2 m

SKU 25065 Only 1 left in stock
Price $248.00per length inc. GST$45.93 /lm inc. GST
Trade account Apply for trade pricing

140 x 65 mm GL10 glulam pine beam, H3 LOSP treated and pink primed, in 3.6 to 7.2 m lengths. For pergola, carport and verandah beams above ground.

Trade customer? Log in or apply for account pricing & 30-day credit.Trade login
Size: 5.4m
Quantity
Need a whole-job price? Send us your plans.Request a quote

Full specifications
Size
140 x 65 mm
Lengths available
3.6, 4.8, 5.4, 6.0 and 7.2 m
Grade
GL10 glue-laminated (glulam)
Material
Radiata pine
Treatment
H3 LOSP, outdoor above ground
Finish
Pink primer
Weight
About 5.5 kg per metre
Sold as
Single length
Typical use
Pergola, carport and verandah beams, lintels, exposed framing
